TRACER 5 is the high value in-situ pXRF performer synchronizing power, function, precision and accuracy for dynamic, field capable laboratory-like elemental analysis.

Detector window: 8 μm Beryllium

Detector: Proprietary 20mm2 silicon drift detector with < 140 eV @ 250,000 cps Mn Kα; resolution for optimum light element analysis.

Analysis range: Detects from Na to U; analyzes from Mg - U

Size: 27.3 cm x 9.4 cm x 29.5 cm (10.75 in x 3.7 in x 11.6 in) L x W x H

Weight: 1.9 kg (4.1 lbs) with battery; 1.6 kg (3.6 lbs) without battery

Power: Li-Ion battery and charger; AC adapter

Excitation source: Rhodium (Rh) thin window X-ray tube; X-ray generator 6-50 kV with 4.5-195 uA, maximum 4 Watt output. Operator adjustable current and voltage for optimum excitation

Collimation: User changeable collimator; 3 mm and 8 mm collimators supplied

Filters: Operator controlled, motorized 5 position primary beam filter wheel. Manual insertion filter/secondary target slot for factory or user made filters.

Geometry: Features patented SharpBeam beam path for best performance at low power.

Beam path: Capable of selectable beam path of vacuum, helium or air to detect elements as light as Fluorine (F) to as heavy as uranium (U).

Internal camera: Internal VGA CMOS camera with ability to store up to 5 photos per assay.

Interactive touchscreen: High performance and contrast daylight visible TFT LCD 9.4 cm (3.7”) color touchscreen display.

Convenience features: TrueTouch trigger switch, relaxed ambidextrous hand grip strap and EasyAccess rail mount for accessories.

Control software: Full control OS on analyzer and on PC software.

Analysis software: Control of all excitation parameters and live spectra displayed on analyzer. Live spectra and qualitative, semi-quantitative and quantitative analysis on Windows 7 or 10 PC.

Data storage & data transfer: Internal and direct storage on USB drive. Data transfer to PC via USB or Wi-Fi. Bluetooth connectivity for accessories.

System safety: Password protection; Sample proximity sensor; Low count rate (backscatter) shutoff

Languages: Chinese, Chinese simplified, Dutch, English, French, French Canadian, German, Indonesian, Italian, Japanese, Korean, Polish, PortugueseBR, Russian, SpanishMEX, SpanishSPN, Thai, Turkish

Operating environment: -10°C to +50°C (+14°F to 122°F); IP54 dust and splash resistant; Altitude: 2,500 m (8,200 ft)

Certification: CE, FCC part 15
